100W GaN Drone Module Supporting 100-7500MHz Frequency Band And LoRa
Product Details
| Output Power: | 50±0.5 7.5A | Sweep Frequency Rate: | 250K4 Microseconds |
|---|---|---|---|
| Highlight |
100W GaN Drone Module,100W Drone defense Module,7500MHz GaN Drone Module |
||
Product Description
Model1:5800-100W-SG
Parameters
| Test item | Metric | Unit | Remarks | |
|---|---|---|---|---|
| frequency range | 5150-5350 /5725-5850 | MHz | With an efficient sweep source/Customizable frequency band |
|
| working voltage | 32 | V | / | |
| gain | 45-50 | db | / | |
| Output Power | 50±0.5 | dBm | 7.5A | |
| Output port in SWR | ≤1.30 | / | No power supply, the grid points the test | |
| High and low temperature test |
Working environment temperature: (℃) | -40～+55 | ℃ | |
| Power stability | 1.0 | dB | -40℃~+55℃ | |
| Power supply requirements | ≥15A | / | A CW output of 100W | |
| Power supply interface | 7w2 | / | Public head | |
| Enable control | Have a choice | / | High open and low closed | |
| The vibration requirements | / | / | Meet the requirements of Enterprise Customers on-board equipment | |
| The RF input / Output connector | N-KFD | / | Mother head | |
| Size | 170*94*26.5 | mm | Excluding the SMA heads | |
| Mounting Hole | 162.5*86 | mm | M 3*10 | |
| Weight | 0.85 | Kg | / | |
